Gravity Hinge

Concealed Fix

Specifications:

Material#304 Stainless Steel
Nylon Inserts
Stainless Steel Snap-on Covers
FinishAuthentic Industrial Stainless Steel
MountingScrew Fix
Minimum Hinge Clearance For Lift Off Hinges35mm
SpecifyLeft Hand, Hold Closed. Assists door to move towards Hold Closed position
Left Hand, Hold Open. Assists door to move towards Hold Open position
Right Hand, Hold Closed. Assists door to move towards Hold Closed position
Right Hand, Hold Open. Assists door to move towards Hold Open position
FeaturesGravity assisted door opening/door closing with lift off capability.
Load Rating15Kg per hingeNote: 3 Hinges per door is recommended to prevent door bowing
NoteFor optimum performance –
2 hinges per door up to 30Kgs
For doors over 30Kg allow for 15Kg per hinge
All hinges are available with or without fixings.
Please nominate your requirements at the time of ordering.
DisclaimerGravity hinges contain no mechanical components. The functionality of these hinges can vary depending on the environment.
When selecting this product, please view our Product Disclosure Statement in the Care and Maintenance Download below.
